Primary Features of the BL Lift

Features that make this lift perfect for your blasting operation include:

• Height and reach: Standard models offer platform heights from 6 to 21 feet, with extended outward reach up to 13 feet, 4 inches. Models with platform heights up to 40 feet are available with additional engineering.
• Platform capacity: The standard 48in x 30in platform supports up to 400 pounds and includes sealed entry gates and safety harness attachment points.
• Speeds: The three-axis positioning moves at variable speeds up to 40 feet per minute on the X-axis and 15 feet per minute on Y and Z axes, allowing precise operator placement.
• Air requirements: The BL requires 80 scfm at 100 psi for efficient operation. The unit includes an unoiled auxiliary air connection and a breathing air connection point.
• Control system: Hand controls manage vertical and inward and outward movement, foot controls handle left and right positioning, and the base controls manage the raising and lowering functions.

Safety Features and Blast Environment Protection

Our BL lift is ideal for applications where powder, sand, grit and welding dust are in the atmosphere. Our engineers can custom-configure a BL lift to meet the needs of your operational requirements. This unit includes safety systems designed for hazardous blast booth conditions, including:

• Sealed construction: Protected components and sealed construction resist damage from abrasive media.
• Emergency systems: E-stop disables all controls, E-down allows descent when air supply fails, and the inertial chain brake detects uncontrolled movement.
• Operator protection: The blast hose hook system reduces fatigue, the breathing air connection supports supplied air respirators, and the main air shut-off provides lockout capabilities.

Personnel Lifts for Paint & Blast Applications

Standard 3-axis BL

Extended Reach 3-Axis BL
